UW-2000 超声波液位计

GENERAL

UW-2000, ultrasonic level monitor is a small but high-cost-perfor- mance level monitor in use of ultra sound.

It has a compact and clean body made of polypropylene. It is suitable for the level management of pure water and/or chemical substances. 4 to 20 mA DC current output, two alarm output for high and low level detection. UW-2000 enables you simple and easy level moni- toring and controlling.



FEATURES

❑ Low cost, small, light and compact.

❑ Simple and clean construction made of polypropylene.

❑ Suitable for semi-conductor process and food industries which re- quire non-contact level measurement of water, pure water and chemical substances.

❑ Superb for remote level control by 4 to 20 mA DC output and 2 points alarm output.

❑ Shows level and parameters by LED display for monitoring and data setting using key-switches.

❑ Available with CE marking for EMC.



SPECIFICATION

● Measuring range 4.0 m Max.  (UW-2100)

9.99 m Max. (UW-2200)

● Minimum output range 0.2 m

● Blocking distance 0.25 m (UW-2100)

0.50 m (UW-2200)

● Ultrasonic frequency 100 kHz (UW-2100)

50 kHz (UW-2200)

● Beam angle 7 o (Half angle)

● Indication (Inside cover)

Level indication 3-digit LED indication (Character height 8mm, red)

Indication unit : cm

Parameter indication : change with key - switches

● Measuring accuracy

Indication accuracy ±0.25% of max. measuring range or 1 cm

(whichever is the larger)

● Setting (free setting with key - switches inside the body) High and low alarm level

Current output level range Number of sampling data Other display units selectable
