UL6400 便携式超声波流量计

OUTLINE

UL6400 is the portable type ultrasonic flowmeter driven by an built- in battery.

Anytime and anywhere, the handy ultrasonic flowmeter measures the various kinds of liquid flow rate just by clamping the sensor on the surface of the existing process lines and by easy setting-up of parameters.



FEATURES

❏ Wide measuring ranges

A set of UL6400 covers the wide ranges of flow measurement from 15 mm to 1500 mm in pipe sizes.

❏ Portable and easy to handle

With all instruments and accessories packed, you can carry and store a rugged plastic trunk with casters anywhere you want.

❏ Battery driven

The built-in battery allows UL6400 to work as long as 14 hours without charging. The attached AC adapter makes UL6400 work continuously while charging the battery.

❏ High performances

Not only the flow rate and total flow, but also the measuring sta- tus, error messages and battery power are displayed. Data are stored in the USB memory for further data processing.

❏ Compensation of flow rate in low Reynolds number domain Inputting the kinematic viscosity compensates the flow rate in the low Reynolds number domain using inhouse calculation function.

❏ Lining pipe

By inputting the lining data, flow rate in lining pipe is measured without time-consuming calculation.



APPLICATIONS

(1) Flow measurement of process lining where no flowmeters are installed

One UL6400 can measure a multiple of flow lines where no flowmeters are installed. It saves your cost by applying it for various services.

(2) Checking of existing flowmeters

Bring UL6400 to the subject pipe lines for checking of the exist- ing flowmeters. You can compare the flow rate measured by existing ones with the one by UL6400.

(3) Checking of pump performance

For checking of the pump discharge flow rate by the portable UL6400.

(4) Temporary flow measurement

For temporary flow measurements in such services as start-up, periodical flow checks and during malfunctioning of the existing flowmeters including applications in remote area without power source.

(5) For corrosive liquids

The non-contact measurement where the sensor is installed on the exterior surface of pipe ensures the anti-corrosion and anti- erosion. UL6400 is compatible with the pipes with linings also.
